Description
The TopLobe series is available in 12 different sizes. Shaft seal options include single and double mechanical as well as lip seals. Multi-foot for vertical or horizontal mounting. Heating/cooling systems for front cover. Built-on safety relief valves as an option. Connections from 20 mm to 150 mm. Benefits
Features
- Simple, clean and robust construction – Hygienic, minimum risk of product entrapment, easy to clean either by CIP, SIP or manually, short cleaning downtimes
- Easy maintenance – Easy service and maintenance, simple gearbox construction
- Gentle product handling – Traditional tri-lobe design gives gentle handling, low pulsation and capability of handling particles
- Large selection of shaft seals – Easily interchangeable with other seal types, short downtimes
- Shim-free, oil lubricated gearbox – Easy to service, longer life
- ATEX Certified
- CE Certified
Details
| Rotor case: | Stainless steel 316L |
|---|---|
| Rotors: | Duplex stainless steel, FPM, Nitrile rubber |
| Max. capacity: | 125 m3/h |
| Max. working pressure: | 22 bar |
| Max. speed: | 1 400 rpm |
